Agentic AI Architecture: What the Pieces Actually Do

"Agentic AI architecture" names a handful of plain pieces wired around a model, not a single smarter model doing more on its own. The model itself only ever does one thing — read some text and produce some text. Everything that makes a system "agentic" sits around that: a catalogue of tools it is allowed to call, somewhere to keep track of what has already happened, and a runtime that keeps the loop going — call the model, read what it asked for, run the tool, feed the result back in, repeat — until a stopping condition is met. Most of the engineering effort in a real agentic system goes into that runtime and its bookkeeping, not into making the model smarter.

The pieces, named plainly

• —The model — reads the current state of the task and decides the next step: answer directly, or call a specific tool with specific arguments. Anthropic’s own tool-use documentation describes this as the model choosing when and how to call a tool as part of reasoning through a task, rather than a fixed script deciding for it.
• —The tool catalogue — the finite list of actions the model is actually allowed to take: look up a record, send an email, run a calculation. A tool the model was never given cannot be called by accident, which makes this list the main lever for limiting what can go wrong.
• —Memory — what the system remembers between steps, and sometimes between separate runs. Working memory holds the current task’s state; longer-lived memory can carry facts across sessions, which is exactly where stale information quietly creeps back in.
• —The orchestrator — the runtime loop that actually calls the model, executes whatever tool it asked for, decides whether to retry a failed step, and checks whether a stopping condition has been met. This is "the architecture" in the name far more than the model is.
• —Evaluation and logging — whatever records what happened at each step, so a wrong result can be traced back to the specific tool call that caused it rather than treated as one unexplained bad answer.

A worked example

Take a concrete task: "find the status of invoice 4471 and email the client an update." The orchestrator passes that instruction to the model. The model decides it needs information first, and calls a lookup tool with the invoice number as its argument. The orchestrator runs that tool against the real system, gets back a status, and feeds the result to the model. The model now decides it has enough to act, and calls a send-email tool with a drafted message. The orchestrator runs that tool, logs that an email was sent, and reports the task complete — four steps, two tool calls, one piece of memory (the invoice status) used once and then discarded.

Nothing about that sequence required a cleverer model than the one that would have answered a single question. What it required was a lookup tool that exists, a send-email tool that exists, and a runtime that correctly passed the result of the first call into the second. Most agentic failures trace back to one of those three being wrong, not to the model reasoning badly.

Where it breaks

• —An ambiguous tool catalogue. Two tools with similar names and overlapping purposes — "update_invoice" and "update_invoice_status" — give the model a real chance to call the wrong one and get back a result that looks perfectly normal.
• —A retry that re-runs a side-effecting step. If the orchestrator times out waiting for the email tool and retries the whole step, and the email actually went out the first time, the client gets the update twice — a failure in the runtime’s retry logic, not in anything the model decided.
• —Stale memory carried into a new task. A fact cached from last week’s run — an old invoice status, an outdated price — can get reused without anyone re-checking it, because nothing in the architecture forces a refresh.
• —A wrong tool call that still returns something. A lookup against the wrong invoice number returns a valid-looking row for a different invoice entirely, and nothing downstream knows to question it — a documented property of how these systems can produce fluent, confident output regardless of whether the underlying step was right.
• —A tool catalogue with more reach than the task needs. Giving the model a general "run_sql" tool when the task only ever needs one specific lookup is the kind of unscoped permission OWASP’s Top 10 for LLM applications groups under "excessive agency" — the risk is not that the model will misuse it on purpose, but that a single wrong call now has a much bigger blast radius.

A smarter model picks the right tool more often. It does not make a retry safe to run twice, or stop a stale fact from being reused. Those are architecture problems, and no amount of model quality fixes them.

Checks before you build or trust one

1. 01Make every side-effecting tool safe to call twice — check whether an action already happened before repeating it — rather than trusting the orchestrator never to retry at the wrong moment.
2. 02Separate read tools from write tools in the catalogue, and require an explicit confirmation step before any write tool runs, so a wrong call that only reads something costs you a stale answer rather than a real action.
3. 03Give every tool a narrow, specific purpose rather than one broad tool that can do several things — the narrower the tool, the smaller the damage from calling the wrong one.
4. 04Log the model’s reasoning for each tool call alongside the call itself, not just the final result, so a wrong outcome can be traced to the step that actually caused it.
5. 05Set an explicit limit on how long memory from one run can be trusted in another, and build the habit NIST’s AI Risk Management Framework recommends generally: decide what you will verify before the system runs, not after a stale fact causes a visible problem.

Where this sits next to the rest of the agent landscape

Agentic framework covers whether you need a packaged runtime at all for a given task, rather than building the loop above by hand. Agentic workflows covers what this architecture actually looks like once it is running on a real task, and agentic AI vs generative AI covers the more basic distinction this whole piece assumes — a model that drafts versus one wired into a loop that acts. An agent that controls a computer screen directly is the same architecture with one tool swapped for something far less scoped — a screenshot and a synthetic click instead of a named function — which is exactly why its failure modes are broader.

What to do Monday

Before trusting any agentic system with a real task, list its tool catalogue explicitly and ask, for each one, what happens if it runs twice by accident and what happens if the model calls the wrong one. AI agent builder covers what you are actually assembling if you are building this yourself, and intelligent process automation covers deciding whether a task is even worth this much setup before you build the architecture for it.
